BLC-450 HD LCD Digital Microscope Camera (Aptina MT9P031 Sensor, 5.0MP)

BLC-450

BLC-450 HD LCD Digital Camera is a brand new high performance and highly cost-effective, super reliable HD LCD camera which combines an full HD camera and a retina HD LCD screen.

Delivery

FOB

minimum order

1 set

Supply Ability

10000set / Month

Country of Origin

Beijing,China

Stock Time

28Day

Quantity

Contact Now

add to cart

Introduction

BLC-450 HD LCD Digital Camera is a brand new high performance and highly cost-effective, super reliable HD LCD camera which combines an full HD camera and a retina HD LCD screen. With the built-in software, the BLC-450 can be controlled by a mouse to take pictures, take videos and save to SD card.

Feature

1. Control camera with mouse from USB port, no shaking.
2. 11.6” retina HD LCD Screen, high definition and high quality color reproduction.
3. 5.0MP still image capture and 1080P Video Recording.
4. Save image and video to SD card.
5. Also can be connected to PC and take picture, take video, do measurement and analyze images.
6. Standard C-mount Interface for different microscopes.

Application

BLC-450 HDMI LCD digital camera is specifically developed for different microscopy applications. It can be widely used in medical diagnosis, industrial production and inspection, laboratory research and related microscopy field for image, video capture and analysis. It is mainly used for following areas:
1. Biological Teaching Digital Imaging
2. Live Cell Imaging
3. Surgical Microscopic Imaging
4. Pathology
5. Cytology
6. Defect Analysis
7. Semiconductor Inspection
8. Navigation for Processed Imaging
9. Industrial Optical HD Digital Imaging
10. Astronomical Observation

Interface on the Camera Body

HDMI Camera	Image Sensor	CMOS, Aptina MT9P031
	Sensor Size	1/2.5"
	Video Resolution	1920 × 1080
	Image Resolution	2592 × 1944
	Frame Rate	1920 × 1080 15fps via USB2.0 1920 × 1080 15fps via HDMI
	Data Record	SD Card (4G)
	Video Record	1080p 15fps @ SD Card 1080p 15fps @ PC
	Scan Mode	Progressive
	Electronic Shutter	Electronic Rolling Shutter
	A/D conversion	8 bit
	Color Depth	24bit
	Sensitivity	510mV
	Dynamic Range	60dB
	S/N ratio	40.5dB
	Exposure time	0.001 sec ~ 10.0 sec
	Exposure	Auto/Manual
	White balance	Auto
	Settings	Gain,Gamma,Saturation,Contrast
	Built- in software	Cloud 1.0 version
	PC software	Capture2.0
	Output model 1	USB2.0
	Output model 2	HDMI
	System Compatible	Windows XP/Vista/Win 7/Win 8/10(32 and 64-bit ), MAC OSX
	Optical port	C- Mount
	Power Supply	DC 12V /2A
	Operational Temperature	0-60°C
	Humidity	45%-85%
	Storage Temperature	-20-70°C
Retina Screen	Screen Size	11.6 inch
	Aspect Ratio	16:9
	Display Resolution	1920 × 1080
	Display Type	IPS-Pro
	Brightness	320cd/m2
	Static Contrast Ratio	1000:1
	Input	1*HDMI Port
	Power Supply	DC 12V /2A External Adapter
	Dimension	282mm×180.5mm×15.3mm
	Net Weight	600g

Sample Images
